Automatic openers >> Swing gates

A Swinging type gate (which swings backwards into the driveway rather than sliding sideways behind the fence) can be heavy and difficult to manoever into place by hand. The Automatic operator is the answer. Please look through the Fadini, ATA and Pirie ranges below which cater for different applications from residential to commercial.

Fadini Nupi 66

Fadini's Nupi 66

NUPI 66 is an oil-hydraulic actuator to operate double swinging gates where each gate has a maximum recommended width of 2 meters. A linear streamlined profile makes it the ideal solution to automate your gates respecting the aesthetic appearance and design of gate. It can suit a variety of applications ranging from the light residential, semi-intensive requirements of house owners and block of flats to heavy duty service in particular applications.
Fadini the Gate Opener
Nupi 66 logo
BFT Phobos Swing gate operator



BFT Phobos Swing Gate Operator

The low voltage safety and the new design of PHOBOS BT make of it the
ideal irreversible gearmotor for residential swing gates.
• Magnetic limit switches adjust the door opening and closing movements.
• Maximum anti-squash safety guaranteed by a special electronic device,
adjustable for each motor, and inverts the direction in case of obstacles in
opening and closing.
• Operation in case of power supply failure is guaranteed by a battery back up
unit (BT BAT) which can be supplied on request.



BFT Virgo Swing Gate operator


BFT Automation
BFT Virgo

• Compact shape with minimum dimensions and articulated arm.
• Versatile installation even on small pillars.
• Maximum anti-squash safety guaranteed by a special electronic device,
adjustable for each motor, and inverts the direction in case of obstacles in
opening and closing.
• The irreversible operator, fitted with mechanical stops, keeps the gate locked in the
open or closed position.
• Features of control panel, with integrated receiver and limit switches for both directions
of travel, assuring safety and quality.
• Phototest function that automatically checks correct photocell operation.
• Easy programming thanks to a control unit fitted with a three-key display panel.
• Slowdown may be set at 3 different speeds during both opening and closing (from
the built in control panel)

Fadini Hindi 880 Sprint
Hindi 880 Sprint Swing gate operator
Click to see operator in situ


Fadini the Gate Opener
The Fadini Hindi 880 comes in 2 models the standard and the Sprint (pictured left)
HINDI 880 Sprint belongs to the new operators “Series 80”. It is an oil-hydraulic unit with improved engineering features such as the pressurized oil circuit and the pushing power. In fact it is equipped with a specially designed lobe pump to ensure constant, smooth revolutions and, consequently, an extremely reliable performance in compressing oil. This makes HINDI 880 Sprint a very quiet running, long life unit, ideal for the automation of swinging gates, residential or light industrial.
Hindi 880
Hindi 880 automatic gate opener accessories and security addons
Hindi 880 series accessories for gate security, automatic operation, digital security entry devices and remote operation
Aproli 280
Aproli 28O Swing gate operator
Click to see unit in place.
Aproli 280
FADINI APROLI 280 BATT gate operator has been designed to suit applications where large pillars are involved and the gates can hang in any required position. The distance between the gate and the motor is taken up by an articulated arm that can be adjusted on site during installation. The anti-crush design ensures maximum safety for people during operations. Aproli 280 BATT is made up of a motor pump and a jack coupled together to make a dual assembly, ie. oil-hydraulic and mechanical, performing as one unit, very compact in size. The driving force in open and close operations is controlled by safety pressure valves, which ensure smooth, anti-crush movements of the equipment in full respect of safety and security.Fadini the Gate Opener
Fadini Drive 700 buried unit
Drive 700 buried
Click for photo
Drive 700 with cover off
FADINI DRIVE 700 hydraulic automation systems are designed and built for underground installation, at the foot of gates or doors. Even pre-existing gates and doors can be invisibly automated in this way. Automatic control is achieved by mounting a hydraulic jack on each wing. The jack is connected, by copper tubes, to a hydraulic unit with a drive pump in an oil bath. The pump is equipped with highly sensitive maximum pressure "by pass" valves. These, correctly adjusted, guarantee maximum protection against crushing accidents.
Fadini the Gate Opener

Drive 700
